Alroc DBT LV Cable End Stripper 16 to 150mm²
- Alroc DBT LV Cable End Stripper 16 to 150mm²
- The DBT cable end stripper enables a user to strip the insulation from the end of secondary distribution cables from 16mm2 to 150mm2.
- An integrated ruler engraved on the tool enables the user to accurately control the stripping length.
- To strip a cable, measure the amount of insulation to removed using the integrated ruler and hold the cable at this point. Insert the cable into the relevant strip hole and twist the DBT tool to remove the insulation. Once the tool reaches your hand you have reached the length of strip required. See video for demo.
- Specification
- 6 sections : 16mm2 - 25mm2 - 35mm2 - 54.6mm2 - 70mm2 - 150m²
- Max. length for 35mm²: 55m
- Max length for 54,6mm²: 70mm
- Max length for 150mm²: 70mm
Alroc DBT demo video
