E-Z Hook XKM Double Gripper Test Connections
- E-Z Hook XKM Double Gripper Test Connection
- The double gripper is designed for "hard to make" test connections of varying sizes and shapes. The narrow configuration allows stacking of the test connectors side-by-side for high-density IC packages and SMD surface mount components.
- Construction: A Single contact blade of Stainless Steel formed into two hooks and two 0.025" / 0.635mm square pins...Permits connection to 0.025" / 0.635mm square or 0.031" / 0.787mm round push-on adapters and jumpers. The blade is retracted by a single Stainless Steel compression spring. Both the Hypo-action plunger and tip housing are moulded in durable Nylon.
- Features:
- Double grip Hooks assure solid positive contact.
- Narrow nose configuration (0.050" / 1.27mm width) is ideal for side-by-side stacking.
- Dual leads and application versatility.
- Easy-to-use spring loaded design.
- Available in 10 standard Colours
- Quality constr
uction
Visit the Warwick Test Supplies website for more information on E-Z Hook XKM Double Gripper Test Connections
