Pomona 5056 Triaxial Male 2 Lug Connector to Cable
  • Pomona 5056 Triaxial Male 2 Lug Connector to Cable
  • The 5056 Triaxial male plug connector fits Belden 9222 triaxial cable, and has a 6.17mm (0.242”) O.D. It has a 50 Ohm impedance and is rated at 500V, 500 MHz with a maximum operating temperature of 165 Deg C. The body is brass with a nickel finish with a gold plated centre contact.
  • Materials
  • Body and Fittings: Brass, Tarnish Resistant Plating
  • Center Contacts: Male: Brass, Gold Plated
  • Outer Contact: Beryllium Copper, Gold Plated
  • Dielectric: PTFE

Specifications

  • Voltage: 500 Vrms
  • Impedance: 50 Ohm
  • Temperature: -65° C. (-85° F.) to +165° C. (+329° F.)
  • Frequency Range: DC to 500 MHz

View the datasheet for more information.

Pomona 5056 Triaxial Male 2 Lug Connector to Cable

Visit the Warwick Test Supplies website for more information on Pomona 5056 Triaxial Male 2 Lug Connector to Cable
